Circular Permanent Lifting Magnet
Description
Our Circular Permanent Lifting Magnets have a round, multi-pole clamping surface, designed for lifting rings, sleeves, bearing housings, flange plates and similar work pieces.
The load specification applies to full surface contact with work pieces which overlap D inside to outside D (see table dimensions);
| Model | D (mm) | Da-Di (mm) | H (mm) | Hs (mm) | Bs (mm) | Material Thickness (mm) | Max Load capacity (kg) | Max Load cm² | Unit Weight (kg) |
| FXC-175 | 120 | 114-40 | 130 | 138 | 185 | 10 | 175 | 3.5 | 10 |
| FXC-250 | 160 | 152-65 | 145 | 153 | 210 | 12 | 250 | 3.5 | 14 |
| FXC-450 | 250 | 240-100 | 155 | 168 | 275 | 15 | 450 | 3.5 | 23 |
