Description
Handheld Demagnetiser type DEM-HD2
Intended Use
The hand demagnetizer is a device with a light-metal body which can be used for various purposes:
• as a demagnetizer
• as a magnetic separator
• as a magnet for loose material
Features
Coil incorporated into a moulded plastic casing
Wide grip handle for a better grip
Pulse on/off button with indicator light. This device has a duty cycle of 20%. Its use time must not exceed 10 minutes
A part to be demagnetized must be exposed to an alternating magnetic field that decreases H (Has 105). Residual magnetism in a part can come either from exposure to a magnet (machining on a magnetic plate, lifting with magnetic carriers, etc.) or from machining the part itself (friction, molecular change, etc.). In order to demagnetize large parts, either to comply with specifications (automotive standards, etc.) or to carry out machining (on a wire machine for example), the demagnetizer is passed over the part at a low and constant speed (about 0.2 m/sec). It is essential to remove the demagnetizer from the room 20 to 30 cm before turning it off. Active area 40mm.
Supplied with: – 3 meters of cable
Length: 200mm
Width: 145mm
Height: 150mm
Weight: 2.2kg
Standard Power Supply: 230V – 50 cycles
(specific voltage can be provided) Consumption: 250VA
Applications
Suitable for most applications
